| Compatibility | Intel Socket: LGA1851, LGA1700; AMD Socket: AM5, AM4; PI | NNPI: 319 | 259; Thermal Paste: MX-6 (0.8 g); Promise: 6 Years; Operating Ambient Temperature: 0–40 °C; LED Connector: 3-Pin A-RGB Connector; All-In-One Connector: 4-Pin PWM Connector; Splitt Connector: 3x 4-Pin PWM Connector |
| Pump/Cold Plate | Pump: 800–2800 rpm (PWM controlled); Current | Voltage: 0.35 A | 12 V DC; Cold Plate: Copper, Micro Skived Fins; Tube Length: 17.72 inches; Tube Diameter: Outer: 0.49 inches, Inner: 0.24 inches |
| VRM Module | VRM Fan: 400–2500 rpm (PWM controlled); Current | Voltage: 0.05 A | 12 V DC; LEDs: 12x A-RGB LEDs; Current | Voltage: 0.40 A | 5 V DC |
| Radiator Fans | General: 2x P14 PWM PST A-RGB (white); Speed: 200–1900 rpm; Air Flow: 69.90 cfm | 117.06 m³/h; Static Pressure: 2.0 mmH₂O; Bearing: Fluid Dynamic Bearing; Current | Voltage: 0.17 A | 12 V DC; Cable Length: 1.57 inches; Connector: 4-Pin PWM Connector |
| RGB | LEDs: 12x A-RGB LEDs; Current | Voltage: 0.40 V | 5 V DC; Cable Length: 1.57 mm + 3.15 inches; Splitter Cable; Connector: 3-Pin A-RGB Connector + 3-Pin Plug |
| Size & Weight | Radiator + Fans: 12.48 (L) x 5.51 (W) x 2.56 (H) inches; Radiator: 12.48 (L) x 5.43 (W) x 1.5 (H) inches; Weight: 62.26 oz. |
| Conditionally compatible** | ASRock: B650E PG-ITX WiFi, Z790 Taichi Lite ASUS ROG: Z790 Taichi Lite, Crosshair X670E Extreme, Maximus Z690 Apex, Maximus Z690 Extreme, Maximus Z790 Apex (Encore), Maximus Z790 Extreme, Maximus Z790 Formula, Strix B650E-I Gaming WIFI, Strix X570-I Gaming, Strix X670E-E Gaming WIFI, Strix X670E-I Gaming WIFI GIGABYTE: B650E AORUS Master, X670 AORUS Pro AX, X670E AORUS Xtreme, Z690 AORUS Master/Ultra/Xtreme, Z690I AORUS Ultra DDR4, Z790 Aero G, Z790 AORUS Master, Z790 AORUS Xtreme (X) |
| Incompatible | ASRock: A320TM-ITX, X300TM-ITX, X570 AQUA, X570 Phantom Gaming-ITX/TB3, X570D4I-2T, Z690 AQUA, Z690 AQUA OC ASUS: Prime A320M-E, Prime B350M-E, Prime B450M-K, ROG Maximus Z690 extreme Glacial, ROG Maximus Z690 Formula, ROG Strix Z690-I Gaming WIFI, ROG Strix Z790-I Gaming WIFI GIGABYTE: B650I AORUS Ultra MSI: MPG X570S Carbon EK X, MPG Z690 Carbon EK X |
| **Note | **The height of the pre-installed M.2_1 cooler overlaps with the pump of the Liquid Freezer III. ARCTIC provides a suitable M.2 cooler. Please contact ARCTIC support to get a free replacement. Please include the invoice of your motherboard as proof with your request. |
