Description
| Category | Details |
|---|---|
| CPU | LGA1700 socket: Supports 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron processors L3 cache varies with CPU |
| Chipset | Intel B760 Express Chipset |
| Memory | 4 x DDR4 DIMM slots, up to 128GB Supports speeds from 2133 MHz up to 5333 MHz (OC) Dual-channel architecture Supports XMP, non-ECC, ECC (non-ECC mode) |
| Graphics | Integrated Intel HD Graphics 1 x HDMI (up to 4K 60Hz) 1 x DisplayPort (up to 4K 60Hz) |
| Audio | Realtek Audio Codec Supports 2/4/5.1/7.1 channels S/PDIF Out support |
| LAN | Realtek Gigabit LAN (1 Gbps) |
| Expansion Slots | 1 x PCIe 4.0 x16 slot (GPU/NVMe) 4 x PCIe 3.0 x1 slots |
| Storage | 2 x M.2 (PCIe 4.0) 4 x SATA 6Gb/s RAID 0, 1, 5, 10 support |
| USB | USB 3.2 Gen 2×2 Type-C (rear) USB 3.2 Gen 2 Type-A USB 3.2 Gen 1 + USB 2.0 ports (rear & internal) |
| Internal Connectors | 24-pin ATX + 8-pin CPU power Multiple fan headers RGB & ARGB headers USB headers TPM header Q-Flash Plus button |
| Back Panel | PS/2 port USB ports (Type-C & Type-A) HDMI + DisplayPort RJ-45 LAN Audio jacks |
| BIOS | 128 Mbit flash AMI UEFI BIOS |
| Features | GIGABYTE Control Center (GCC) Q-Flash / Q-Flash Plus |
| Software | Norton Internet Security (OEM) LAN bandwidth management software |
| OS Support | Windows 11 / Windows 10 (64-bit) |
| Form Factor | ATX (30.5cm x 24.4cm) |
