Description
| TIM | MX-6 (0.8 g) |
|---|---|
| Warranty | 6 Years |
| Operating Ambient Temperature | 0–40 °C |
| Pump Speed | 800–2800 rpm (PWM controlled) |
| Pump Current | Voltage | 0.35 A | 12 V DC |
| Cold Plate | Copper, Micro Skived Fins |
| Tube Length | 500 mm |
| Tube Diameter | Outer: 12.4 mm Inner: 6.0 mm |
| Weight | 2370 g |
| Compatibility | Intel: LGA1851, LGA1700 AMD: AM5, AM4 |
| PI | NNPI | 420 | 376 |
| Radiator Material | Aluminium |
| Radiator Dimensions | 458 (L) × 138 (W) × 38 (H) mm |
| VRM Fan Speed | 400–2500 rpm (PWM-controlled) |
| VRM Fan Current | Voltage | 0.05 A | 12 V DC |
| Radiator Fans | 3× P14 Pro |
| Fan Speed | 400–2500 rpm |
| Airflow | 110 CFM | 186 m³/h |
| Static Pressure | 5.2 mmH₂O |
| Bearing | Fluid Dynamic Bearing |
| Fan Current | Voltage | 0.35 A | 12 V DC |
| Fan Connector | 4-Pin Fan Plug |
