Description
| Product Specifications | |
|---|---|
| TIM | MX-6 (0.8 g) |
| Warranty | 6 Years |
| Operating Ambient Temperature | 0—40 °C |
| Pump | 800–2800 rpm (PWM controlled) |
| Current | Voltage (Pump) | 0.35 A | 12 V DC |
| Cold Plate | Copper, Micro Skived Fins |
| Tube Length | 500 mm |
| Tube Diameter | Outer: 12.4 mm Inner: 6.0 mm |
| Weight | 2358 g |
| Compatibility | |
| Intel | LGA1851, LGA1700 |
| AMD | AM5, AM4 |
| PI | NNPI | 420 | 376 |
| Radiator | |
| Material | Aluminium |
| Dimensions | 458 (L) x 138 (W) x 38 (H) mm |
| VRM Module | |
| VRM Fan | 400–2500 rpm (PWM-controlled) |
| Current | Voltage (VRM Fan) | 0.05 A | 12 V DC |
| LEDs | 12x A-RGB Gen2 LEDs |
| Current | Voltage (LEDs) | 0.40 A | 5 V DC |
| Radiator Fan | |
| General | 3x P14 Pro A-RGB |
| Speed | 400–2500 rpm |
| Airflow | 110 cfm | 186 m³/h |
| Static Pressure | 5.2 mmH2O |
| Bearing | Fluid Dynamic Bearing |
| Current | Voltage (Fan) | 0.35 A | 12 V DC |
| Connector | 4-Pin Fan Plug |
| RGB | |
| LEDs | 12x A-RGB Gen2 LEDs |
| Current | Voltage (RGB) | 0.40 A | 5 V DC |
| Connector | 3-Pin A-RGB Plug + 3-Pin Socket |
