Description
| Category | Specification |
|---|---|
| Model Features | Superb Productivity – Dual Channel DDR5 Rock-Solid Durability – 4+1+1 Power Phase, Dr.MOS for Vcore EZ Update – BIOS Flashback Button, ASRock Auto Driver Installer EZ Troubleshooter – ASRock Post Status Checker |
| CPU Support | AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors |
| Chipset | AMD A620A |
| Memory | Dual Channel DDR5 Memory Technology 2 x DDR5 DIMM Slots Supports DDR5 non-ECC, un-buffered memory up to 6800+(OC) Maximum Capacity: 128GB Supports XMP and EXPO Memory Profiles |
| BIOS | 256Mb AMI UEFI Legal BIOS with GUI Support |
| Graphics | Integrated AMD RDNA™ Graphics (CPU Dependent) 1 x HDMI 2.1 (4K @ 120Hz, HDR, HDCP 2.3) 1 x D-Sub (1920×1080 @ 60Hz) |
| Audio | 7.1 Channel HD Audio (Realtek ALC897 Codec) |
| LAN | Gigabit LAN 10/100/1000 Mb/s (Realtek RTL8111H) |
| Expansion Slots | 1 x PCIe 4.0 x16 Slot 2 x PCIe 3.0 x1 Slots 1 x M.2 Key-E Slot for WiFi/Bluetooth Module 15μ Gold Contact PCIe x16 Slot |
| Storage | 1 x Hyper M.2 (PCIe Gen4x4, 2280) 1 x Ultra M.2 (PCIe Gen3x4 / SATA3, 2260/2280) 2 x SATA3 6Gb/s Ports NVMe SSD Boot Support |
| RAID | SATA: RAID 0, RAID 1 NVMe: RAID 0, RAID 1, RAID 10 |
| USB Ports | Rear: 4 x USB 3.2 Gen1 Type-A, 4 x USB 2.0 Front: 1 x USB 3.2 Gen1 Type-C, 2 x USB 3.2 Gen1 Type-A, 4 x USB 2.0 |
| Internal Connectors | 1 x Power LED & Speaker Header 1 x RGB LED Header 3 x Addressable RGB Headers 1 x CPU Fan Header 3 x Chassis/Water Pump Fan Headers 1 x 24-pin ATX Power Connector 1 x 8-pin CPU Power Connector 1 x Front Audio Header 2 x USB 2.0 Headers 1 x USB 3.2 Gen1 Header 1 x Front USB Type-C Header |
| Rear I/O | 2 x WiFi Antenna Mounting Points 1 x D-Sub Port 1 x HDMI Port 4 x USB 3.2 Gen1 Type-A 4 x USB 2.0 1 x RJ-45 LAN Port 1 x BIOS Flashback Button Audio Jacks (Line-In / Front Speaker / Microphone) |
| Software | ASRock Motherboard Utility (A-Tuning) ASRock Polychrome SYNC |
| UEFI Features | ASRock Full HD UEFI ASRock Auto Driver Installer ASRock Instant Flash |
| Accessories | 1 x I/O Shield 2 x SATA Data Cables 1 x M.2 Screw |
| Form Factor | Micro ATX (24.4 cm x 22.9 cm), 2oz Copper PCB |
| Operating System | Windows 10 64-bit / Windows 11 64-bit |
| Certifications | FCC, CE, ErP/EuP Ready |
