| Feature | Details |
|---|
| Unique Features | ASRock Super Alloy, ASRock Ultra M.2, ASRock Full Spike Protection, ASRock Live Update & APP Shop |
| CPU Support | 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700), Digi Power design, 6 Power Phase design |
| Chipset | Intel® H610 |
| Memory | Dual Channel DDR4, 2 x DIMM Slots, Up to 3200MHz, Max 64GB |
| BIOS | 128Mb AMI UEFI Legal BIOS, ACPI 6.0, SMBIOS 2.7 |
| Graphics | Intel® Xe Graphics, HDMI 2.1, DisplayPort 1.4, D-Sub |
| Audio | 7.1 CH HD Audio (Realtek ALC897/887 Codec) |
| LAN | Gigabit LAN 10/100/1000 Mb/s (Intel® I219V) |
| Expansion Slots | 1 x PCIe 4.0 x16, 2 x PCIe 3.0 x1, 1 x M.2 (WiFi/BT) |
| Storage | 1 x Ultra M.2 (PCIe Gen3x4 & SATA3), 4 x SATA3 |
| Connectors | USB 3.2, USB 2.0, CPU & Chassis Fan Headers, 24-pin ATX Power |
| Rear I/O Ports | HDMI, DisplayPort, USB 3.2, USB 2.0, LAN, Audio |
| Software | ASRock Motherboard Utility (A-Tuning), ASRock EZ Mode |
| Accessories | I/O Shield, 2 x SATA Cables, 2 x M.2 Screws |
| Form Factor | Micro ATX (9.6-in x 7.9-in, 24.4 cm x 20.1 cm) |
| OS Support | Windows 10 64-bit / 11 64-bit |
| Certifications | FCC, CE, ErP/EuP Ready |
