| Category |
Details |
| CPU |
Intel® Socket LGA1851 for Intel® Core™ Ultra Processors (Series 2), Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 |
| Chipset |
Intel® Z890 Chipset |
| Memory |
4 x DIMM slots, max. 256GB, DDR5, Dual Channel Memory Architecture, Supports Intel® Extreme Memory Profile (XMP), NitroPath DRAM Technology, DIMM Fit, ASUS Enhanced Memory Profile III (AEMP III) |
| Graphics |
1 x DisplayPort (Max. 8K@60Hz), 1 x HDMI® (Max. 8K@60Hz), 2 x Intel® Thunderbolt™ 4 supporting DisplayPort and Thunderbolt™ video outputs |
| Expansion Slots |
1 x PCIe 5.0 x16 slot, 1 x PCIe 4.0 x16 slot (x4 mode) |
| Storage |
7 x M.2 slots, 4 x SATA 6Gb/s ports, Supports RAID 0/1/5/10 |
| Ethernet |
1 x Realtek 5Gb Ethernet, ASUS LANGuard |
| Wireless & Bluetooth |
Wi-Fi 7 (802.11be), 2×2 Wi-Fi, Bluetooth® v5.4 |
| USB (Rear) |
2 x Thunderbolt™ 4 (USB Type-C®), 9 x USB 10Gbps (7 x Type-A + 1 x USB Type-C® + 1 x USB Type-C® with 30W PD), 3 x USB 5Gbps (Type-A) |
| USB (Front) |
1 x USB 20Gbps (Type-C®), 2 x USB 5Gbps headers (4 ports), 3 x USB 2.0 headers (6 ports) |
| Audio |
ROG SupremeFX 7.1 Surround Sound, ALC4080 Codec, Impedance sense, 120 dB SNR stereo playback, Supports 32-Bit/384 kHz playback |
| Back Panel I/O |
2 x Thunderbolt™ 4, 9 x USB 10Gbps, 3 x USB 5Gbps, 1 x DisplayPort, 1 x HDMI®, 1 x Wi-Fi Module, 1 x Realtek 5Gb Ethernet, 2 x Gold-plated audio jacks, 1 x Optical S/PDIF, BIOS FlashBack™, Clear CMOS |
| Internal I/O |
1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 5 x 4-pin Chassis Fan headers, 7 x M.2 slots, 4 x SATA 6Gb/s ports |
| Special Features |
Extreme Engine Digi+, ASUS Q-Design (M.2 Q-Latch, Q-Release, Q-LED), ASUS EZ DIY (BIOS FlashBack™, Pre-mounted I/O shield, SafeSlot), Aura Sync |
| Software |
ROG CPU-Z, Dolby Atmos, Armoury Crate, Fan Xpert 4, GameFirst, AIDA64 Extreme (60 days trial), Norton 360 (60 days trial) |
| BIOS |
256 Mb Flash ROM, UEFI AMI BIOS |
| Accessories |
2 x SATA 6Gb/s cables, Thermal pad for M.2 22110, ASUS Wi-Fi Q-Antenna, Cable ties, M.2 Q-Latch package, ROG key chain, ROG Strix stickers |
| Operating System |
Windows® 11 (22H2 & later) |
| Form Factor |
ATX, 12 inch x 9.6 inch (30.5 cm x 24.4 cm) |
