| Model Number | 90MB1IP0-M0UAY0 |
| Socket Type | LGA 1851 |
| Chipset | Intel Z890 |
| CPU Support | Intel® Core™ Ultra Processors (Series 2) |
| Form Factor | ATX (30.5 x 24.4 cm) |
| Memory Slots | 2 x DIMM |
| Memory Type | DDR5 |
| Max Memory Supported | 96 GB |
| Memory Frequency | Up to 9600 MHz (OC) |
| Dual Channel Support | Yes |
| PCIe Slots | 2 x PCIe 5.0 x16 (support x16 or x8/x8 modes) |
| M.2 Slots | 4 x M.2 slots (3 x PCIe 5.0 x4, 1 x PCIe 4.0 x4) |
| SATA Ports | 4 x SATA 6Gb/s |
| Ethernet Ports | 1 x Realtek 5Gb Ethernet |
| Wi-Fi | 2×2 Wi-Fi 7 (802.11be) with Bluetooth v5.4 |
| USB Ports | 1 x USB 20Gbps Type-C, 2 x Thunderbolt™ 4 USB Type-C, 4 x USB 5Gbps Type-A, 4 x USB 10Gbps Type-A |
| Audio Codec | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 + Savitech SV3H712 AMP |
| Power Connectors | 1 x 24-pin Main Power connector, 2 x 8-pin +12V Power connectors |
| BIOS Flashback™ Button | Yes |
| Clear CMOS Button | Yes |
| Warranty | 3 years |
