Description
| Model Number | MCB-D500D-KANN-S01 | |
| Series | MasterBox Series | |
| Size | Mid Tower | |
| Color(s) | Black | |
| Materials – Exterior | Steel, Plastic | |
| Materials – Left Side Panel | Acrylic | |
| Dimensions (L x W x H) | 493 x 217 x 469mm (incl. Protrusions), 429.5 x 205 x 447mm (excl. Protrusions) | |
| Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature) | |
| Expansion Slots | 7 | |
| 5.25″ Drive Bays | N/A | |
| 2.5″ / 3.5″ Drive Bays (Combo) | 2 | |
| 2.5″ Drive Bays | 4 (2+2 combo) | |
| I/O Panel | 2x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Hub | |
| Pre-installed Fans – Front | 3x 120mm CF120 ARGB | |
| Pre-installed Fans – Rear | 1x 120mm (Black) | |
| Fan Support – Top | 3x 120mm, 2x 140mm | |
| Fan Support – Front | 3x 120mm, 2x 140mm | |
| Fan Support – Rear | 1x 120mm | |
| Radiator Support – Top | 120mm, 240mm, 360mm, (44mm max motherboard component height) | |
| Radiator Support – Front | 120mm, 140mm, 240mm, 280mm, 360mm | |
| Radiator Support – Rear | 120mm | |
| Clearance – CPU Cooler | 165mm/6.49″ | |
| Clearance – PSU | 180mm/7.08″ | |
| Clearance – GFX | 410mm/16.1″ | |
| Cable Routing | 19mm/0.74″ | |
| Dust Filters | Front, Top, Bottom | |
| Power Supply Support | Bottom Mount, ATX |
