Description
| MODEL NUMBER | MCB-B511D-KGNN-RGA |
| SERIES | MasterBox Series |
| SIZE | Mid Tower |
| AVAILABLE COLOR(S) | Black |
| MATERIALS | Steel, Plastic, Tempered Glass |
| DIMENSIONS (L X W X H) | 496 x 217 x 469 mm |
| WEIGHT | 6.59 kg |
| MOTHERBOARD SUPPORT | Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*support for up to 12″ x 10.7″, will limit cable management features) |
| EXPANSION SLOTS | 7 |
| 5.25″ DRIVE BAYS | N/A |
| 2.5″ / 3.5″ DRIVE BAYS (COMBO) | 2 (Max.2) |
| 2.5″ DRIVE BAYS | 5 (Max.6) |
| I/O PANEL | 2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Controller, 1x ARGB 2-to-3 splitter |
| PRE-INSTALLED FANS – FRONT | 3x 120mm ARGB Fans |
| FAN SUPPORT – TOP | 3x 120mm, 2x 140mm |
| FAN SUPPORT – FRONT | 3x 120mm, 2x 140mm |
| FAN SUPPORT – REAR | 1x 120mm |
| RADIATOR SUPPORT – TOP | 120mm, 240mm, 360mm, (44mm max motherboard component height) |
| RADIATOR SUPPORT – FRONT | 120mm, 140mm, 240mm, 280mm, 360mm, (75mm clearance) |
| RADIATOR SUPPORT – REAR | 120mm |
| CLEARANCE – CPU COOLER | 165mm/6.49″ |
| CLEARANCE – PSU | 180mm/7.08″ |
| CLEARANCE – GFX | 410mm/16.1″ |
| DUST FILTERS | Front, Top, Bottom |
| POWER SUPPLY SUPPORT | Bottom mount, ATX |
| EAN CODE | 4.71951E+12 |
| UPC CODE | 8.84102E+11 |
