MODEL
Model	R-PXA00G-FC0B-UK
Typev	ATX12V V3.0
SPEC
Product Dimensions	150×160×86mm (W x L x H)
Maximum Power	1000W
Fans	135mm
Topology	Active PFC + Half Bridge SRC LLC + DC to DC
PCI-E Connectors	PCI-E (6+2)Pin x1
Power Good Signal	100-150ms
Hold-up Time	>16ms
Efficiency	≥90% Under Typical Load(50% Loading)
Energy-Efficient	80Plus GOLD/Cybenetics_Platinum
Over Voltage Protection	OPP/OVP/SCP/OTP/OCP/UVP
Approvals	CE/FCC/CCC/TUV-RH/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA/BIS/KC
Erp Regulation	Erp 2014
