Description
| Type | ATX12V v2.4 | ||||||
| Efficiency | Meet 80% efficiency | ||||||
| Support MB Sync | 5V 3-pin Addressable (Digital) RGB Header Only | ||||||
| Dimension (L x W x H) | 140 x 150 x 86 mm | ||||||
| Support C6/C7 power state | Yes | ||||||
| AC Input | 100-130V;220-240V / 3.5A-7.5A / 47-63Hz | ||||||
| DC Output | +3.3V / +5V / +12V / -12V / +5Vsb | ||||||
| Max. Output Current | 15A / 15A / 32A / 0.3A / 2.5A | ||||||
| Max. Output Power | 100W / 384W / 3.6W / 12.5W | ||||||
| Total Power | 500W | ||||||
| Protection | OVP / UVP / OPP / SCP | ||||||
| Main Power | 1 (20+4 Pin) | ||||||
| CPU | 1 (4+4 Pin) | ||||||
| PCI-E | 2 (6+2 Pin) | ||||||
| SATA | 5 (5 Pin) | ||||||
| Molex | 2 (4 Pin) | ||||||
| Floppy | 1 (4 Pin) | ||||||
| Lighting Effect | 30 Neon-Flex RGB | ||||||
| Silent Mode | No | ||||||
| DC to DC | No | ||||||
