| CPU |
AMD Socket AM4, support for AMD Ryzen™ 5000 G-Series, 5000 Series, 4000 G-Series, 3000 G-Series and 3000 Series Processors |
| Chipset |
AMD A520 |
| Memory |
4 x DDR4 DIMM sockets, up to 128 GB (32 GB per DIMM) |
| Memory Speed |
DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz |
| Memory Architecture |
Dual Channel |
| ECC Support |
ECC Un-buffered DIMM 1Rx8/2Rx8 |
| Non-ECC Support |
Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 |
| XMP Support |
Yes |
| Onboard Graphics |
Integrated AMD Radeon™ Graphics (CPU dependent) |
| DisplayPort |
1 x DisplayPort, up to 5120 x 2880 @ 60 Hz, DisplayPort 1.4, HDCP 2.3, HDR |
| HDMI |
1 x HDMI, up to 4096 x 2160 @ 60 Hz, HDMI 2.1, HDCP 2.3, HDR |
| Maximum Shared Memory |
16 GB |
| Audio |
Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN |
Realtek® GbE LAN, 1 Gbps / 100 Mbps / 10 Mbps |
| Wi-Fi |
MediaTek Wi-Fi 6E MT7902, 2.4/5/6 GHz, 802.11 a/b/g/n/ac/ax, 160 MHz |
| Bluetooth |
Bluetooth 5.3 |
| Expansion Slots |
1 x PCIe x16 (PCIe 3.0 x16), 1 x PCIe x1 (PCIe 3.0 x1) |
| PCIe x16 Function |
Supports graphics card or NVMe SSD |
| M.2 |
1 x M.2 Socket 3, M key, 2280, SATA and PCIe 3.0 x4/x2 SSD support |
| SATA |
4 x SATA 6Gb/s, RAID 0 / RAID 1 / RAID 10 |
| USB (Back Panel) |
4 x USB 3.2 Gen 1, 4 x USB 2.0/1.1 |
| USB (Internal) |
2 x USB 3.2 Gen 1 via header, 2 x USB 2.0/1.1 via header |
| Power Connectors |
1 x 24-pin ATX, 1 x 8-pin ATX 12V |
| Fan Headers |
1 x CPU Fan Header, 1 x System Fan Header |
| Internal I/O |
1 x M.2, 4 x SATA 6Gb/s, Front Panel, Front Audio, USB 3.2 Gen 1, USB 2.0/1.1, TPM Header, Clear CMOS |
| Back Panel |
PS/2 Keyboard/Mouse, DisplayPort, HDMI, 4 x USB 3.2 Gen 1, 4 x USB 2.0/1.1, RJ-45, 2 x Antenna Connectors |
| I/O Controller |
iTE® I/O Controller Chip |
| Hardware Monitoring |
Voltage, temperature and fan speed detection; fan fail warning and fan speed control |
| BIOS |
1 x 128 Mbit Flash, AMI UEFI BIOS |
| BIOS Features |
PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Unique Features |
APP Center, @BIOS, EasyTune, Smart Backup, System Information Viewer, Q-Flash |
| Bundled Software |
Norton® Internet Security (OEM version) |
| Operating System |
Windows 11 64-bit, Windows 10 64-bit |
| Form Factor |
Micro ATX |
| Dimensions |
24.4 cm x 24.4 cm |
