Description
| Category | Specification |
|---|---|
| CPU | AM4 Socket: Supports AMD Ryzen™ 5000 series / Ryzen™ 5000 G-Series / 3rd Gen Ryzen™ / 2nd Gen Ryzen™ / 1st Gen Ryzen™ / 2nd Gen Ryzen™ with Radeon™ Vega Graphics / 1st Gen Ryzen™ with Radeon™ Vega Graphics / Athlon™ with Radeon™ Vega Graphics Processors. (Please refer to “CPU Support List” for more information.) |
| Chipset | AMD B450 |
| Memory | 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) — Dual channel memory architecture. Support for DDR4 3600(O.C.) / 3466(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 (operate in non-ECC mode). Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16. Support for Extreme Memory Profile (XMP) memory modules. (Please refer to “Memory Support List” for more information.) |
| Onboard Graphics | Integrated Graphics Processor with: • 1 x D-Sub port — max resolution 1920×1200 @60 Hz. • 1 x DVI-D port — max resolution 1920×1200 @60 Hz. (DVI-D does not support D-Sub via adapter.) • 1 x HDMI port — max resolution 4096×2160 @60 Hz (supports HDMI 2.0 and HDCP 2.2). Maximum shared memory: 16 GB. (Actual support may vary by CPU.) |
| Audio | Realtek® Audio CODEC — High Definition Audio. 2/4/5.1/7.1-channel (To configure 7.1, use HD front panel audio module and enable multi-channel in driver). Support for S/PDIF Out. |
| LAN | Realtek® GbE LAN chip (10/100/1000 Mbit) |
| Expansion Slots | 1 x PCI Express x16 slot (runs at x16, PCIe 3.0). 2 x PCI Express x1 slots (PCIe 2.0). |
| Storage Interface | 1 x M.2 connector (Socket 3, M key; supports type 2242/2260/2280 SATA & PCIe x4/x2* SSD). 4 x SATA 6 Gb/s connectors. Support for RAID 0, RAID 1, RAID 10. * Actual support may vary by CPU. * Supports only M.2 SATA SSDs when using AMD Athlon™-series / certain APUs. |
| USB | Chipset: 2 x USB 3.1 Gen 1 ports via internal header; 6 x USB 2.0/1.1 ports (2 rear, 4 via internal headers). CPU: 4 x USB 3.1 Gen 1 ports on back panel. Back panel totals and internal header distribution described in Back Panel / Internal I/O. |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header, 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6 Gb/s connectors 1 x front panel header, 1 x front panel audio header 1 x S/PDIF Out header 1 x CPU cooler LED strip / RGB LED strip header 1 x USB 3.1 Gen 1 header, 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2×6 pin, for GC-TPM2.0_S module only) 1 x speaker header, 1 x Clear CMOS jumper, 1 x chassis intrusion header |
| Back Panel Connectors | 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 4 x USB 3.1 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 LAN port 3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detection, Temperature detection, Fan speed detection. Overheating warning, Fan fail warning, Fan speed control. (* Fan speed control support depends on installed cooler.) |
| BIOS | 1 x 128 Mbit flash — Licensed AMI UEFI BIOS. PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0. |
| Unique Features | Support for APP Center (available apps vary by model). 3D OSD, AutoGreen, Cloud Station, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, Smart Keyboard, Smart TimeLock, Smart HUD, Smart Survey, System Information Viewer, USB Blocker, Q-Flash support, Xpress Install. |
| Bundled Software | Norton® Internet Security (OEM version); Realtek® 8118 Gaming LAN Bandwidth Control Utility |
| Operating System | Support for Windows 10 64-bit. Support for Windows 7 64-bit (requires AMD Pinnacle Ridge & Summit Ridge CPU and Windows USB Installation Tool from GIGABYTE). |
| Form Factor | Micro ATX Form Factor; 24.4 cm x 20.5 cm |
