| Category | Specification |
|---|
| CPU | AMD Socket AM4, supports:- AMD Ryzen™ 5000 G-Series Processors
- AMD Ryzen™ 5000 Series Processors
- AMD Ryzen™ 4000 G-Series Processors
- AMD Ryzen™ 3000 G-Series Processors
- AMD Ryzen™ 3000 Series Processors
|
| Chipset | AMD B550 |
| Memory | - 4 x DDR4 DIMM Slots
- Supports up to 128GB (32GB per DIMM)
- Supports DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MT/s
- Dual Channel Memory Architecture
- Supports ECC Un-buffered DIMMs (1Rx8/2Rx8)
- Supports Non-ECC Un-buffered DIMMs (1Rx8/2Rx8/1Rx16)
- Supports Extreme Memory Profile (XMP)
|
| Onboard Graphics | Integrated AMD Radeon™ Graphics (CPU dependent)- 1 x DisplayPort 1.4 (5120×2880 @ 60Hz, HDR, HDCP 2.3)
- 1 x HDMI 2.1 (4096×2160 @ 60Hz, HDR, HDCP 2.3)
- Maximum Shared Memory: 16GB
|
| Audio | - Realtek® High Definition Audio Codec
- 2 / 4 / 5.1 / 7.1 Channel Audio
- Supports Audio Jack Re-tasking
|
| LAN | Realtek® Gigabit LAN (10/100/1000 Mbps) |
| Wireless | - MediaTek Wi-Fi 6E MT7902
- Supports Wi-Fi a/b/g/n/ac/ax
- 2.4GHz / 5GHz / 6GHz
- Bluetooth 5.3
- Supports 160MHz Channel Bandwidth
|
| Expansion Slots | - 1 x PCIe x16 (PCIe 4.0 x16 with Ryzen 5000/3000 Series, PCIe 3.0 x16 with G-Series CPUs)
- 1 x PCIe 3.0 x1
|
| Storage | - 1 x M.2 (PCIe 4.0 x4/x2 & SATA, CPU)
- 1 x M.2 (PCIe 3.0 x2, Chipset)
- 4 x SATA 6Gb/s
- RAID 0 / RAID 1 / RAID 10 Support
|
| USB | - Rear: 4 x USB 3.2 Gen 1
- Rear: 4 x USB 2.0
- Front Header: 2 x USB 3.2 Gen 1
- Front Header: 2 x USB 2.0
|
| Internal I/O | - 24-pin ATX Power Connector
- 8-pin CPU Power Connector
- 1 x CPU Fan Header
- 1 x System Fan Header
- 2 x M.2 Slots
- 4 x SATA Connectors
- Front Panel Header
- Front Audio Header
- USB 3.2 Gen1 Header
- USB 2.0 Header
- TPM Header (2×6 Pin)
- Clear CMOS Jumper
|
| Rear I/O Ports | - 1 x PS/2 Keyboard/Mouse Port
- 1 x DisplayPort
- 1 x HDMI
- 4 x USB 3.2 Gen1
- 4 x USB 2.0
- 1 x RJ-45 LAN Port
- 2 x Wi-Fi Antenna Connectors
- 3 x Audio Jacks
|
| I/O Controller | iTE® I/O Controller Chip |
| Hardware Monitoring | - Voltage Detection
- Temperature Detection
- Fan Speed Detection
- Fan Failure Warning
- Fan Speed Control
|
| BIOS | - 1 x 128 Mbit Flash
- AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0
|
| Unique Features | APP Center Support:- @BIOS
- EasyTune
- Smart Backup
- System Information Viewer
- Q-Flash
|
| Bundled Software | Norton® Internet Security (OEM Version) |
| Operating System | - Windows 11 64-bit
- Windows 10 64-bit
|
