| CPU |
| CPU Socket |
LGA1851 |
| CPU Support |
Intel® Core™ Ultra Processors |
| L3 Cache |
Varies with CPU |
| Chipset |
| Chipset |
Intel® Z890 Express Chipset |
| Memory |
| Memory Type |
DDR5 |
| Memory Speed |
DDR5 9200(O.C.) / 9066(O.C.) / 8933(O.C.) / 8800(O.C.) / 8600(O.C.) / 8400(O.C.) / 8266(O.C.) / 8200(O.C.) / 8000(O.C.) / 7950(O.C.) / 7900(O.C.) / 7800(O.C.) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600 MT/s |
| Memory Slots |
4 x DDR5 DIMM |
| Maximum Memory |
Up to 256 GB (64 GB per DIMM) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC Un-buffered DIMM, Non-ECC Un-buffered DIMM, XMP, CUDIMM |
| Onboard Graphics |
| Thunderbolt™ 4 |
1 x Intel® Thunderbolt™ 4 / USB4® USB Type-C®, DisplayPort & Thunderbolt™ video output |
| Thunderbolt Display |
Up to 5120 × 2880 @ 60 Hz, 24 bpp |
| USB4 Display |
Up to 3840 × 2160 @ 240 Hz |
| Front HDMI |
1 x HDMI, up to 1920 × 1080 @ 30 Hz |
| DisplayPort |
1 x DisplayPort, up to 4096 × 2304 @ 60 Hz |
| Display Support |
Up to 3 displays simultaneously |
| Audio |
| Audio Codec |
Realtek® ALC1220 CODEC |
| Audio Channels |
2/4/5.1/7.1-channel High Definition Audio |
| S/PDIF |
Supported |
| LAN & Wireless |
| LAN |
Realtek® 2.5GbE LAN (2.5 Gbps / 1 Gbps / 100 Mbps) |
| Wi-Fi |
Wi-Fi 7 – MediaTek MT7925 / Realtek RTL8922AE |
| Wireless Bands |
2.4 / 5 / 6 GHz |
| Bluetooth |
Bluetooth 5.4 |
| Wi-Fi Standard |
802.11a/b/g/n/ac/ax/be, 11be 160MHz |
| Expansion Slots |
| CPU PCIe Slot |
1 x PCI Express x16, PCIe 5.0, running at x16 (PCIEX16) |
| Additional PCIe Slots |
2 x PCI Express x16, PCIe 4.0, running at x4 |
| Storage |
| M.2 CPU Slots |
1 x PCIe 5.0 x4/x2 + 1 x PCIe 4.0 x4/x2 |
| M.2 Chipset Slots |
2 x PCIe 4.0 x4/x2 (one supports SATA) |
| M.2 Connectors |
4 x M.2 Socket 3 |
| SATA |
4 x SATA 6Gb/s |
| RAID |
RAID 0 / 1 / 5 / 10 for NVMe and SATA storage |
| USB |
| Thunderbolt™ 4 |
1 x USB Type-C®, up to 40Gbps Thunderbolt / 20Gbps USB4 / 10Gbps USB 3.2 |
| USB 3.2 Gen 2 Type-A |
2 x Rear |
| USB 3.2 Gen 1 |
5 x (3 Rear + 2 Internal) |
| USB 2.0/1.1 |
8 x (4 Rear + 4 Internal) |
| Internal I/O |
| Power Connectors |
1 x 24-pin ATX + 2 x 8-pin ATX 12V |
| Fan Headers |
1 x CPU Fan + 1 x CPU Fan/Water Pump + 3 x System Fan + 1 x System Fan/Water Pump |
| RGB Headers |
3 x Addressable RGB Gen2 + 1 x RGB LED |
| Other Connectors |
Front Panel, Front Audio, USB Type-C, USB 3.2 Gen 1, 2 x USB 2.0/1.1, TPM, HDMI, Power, Reset, Q-Flash Plus, Clear CMOS |
| Back Panel Connectors |
| Thunderbolt™ 4 |
1 x USB Type-C® |
| USB |
2 x USB 3.2 Gen 2 Type-A + 3 x USB 3.2 Gen 1 + 4 x USB 2.0/1.1 |
| Network |
1 x RJ-45 |
| Display |
1 x DisplayPort |
| Audio |
1 x Optical S/PDIF Out + 2 x Audio Jacks |
| Wireless |
2 x Antenna Connectors (2T2R) |
| Hardware Monitoring |
| Monitoring Features |
Voltage, Temperature, Fan Speed, Water Cooling Flow Rate, Fan Fail Warning & Fan Speed Control |
| BIOS & Features |
| BIOS |
256 Mbit Flash, AMI UEFI BIOS |
| BIOS Features |
PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Software |
GIGABYTE Control Center (GCC), Norton® Internet Security, LAN Bandwidth Management |
| Special Features |
Q-Flash, Q-Flash Plus, Smart Backup |
| Operating System |
| Supported OS |
Windows 11 64-bit |
| Form Factor |
| Motherboard Size |
ATX Form Factor; 30.5 cm × 24.4 cm |
