| CHIPSET | | AMD B450 |
| | |
| CPU | | Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000 G-Series an |
| | 1000 Series Desktop Processor and Athlon™ with Radeon™ Vega Graphics desktop processors |
| | Socket AM4 |
| | |
| MEMORY | | 2x DDR4, Maximum Memory Capacity 64GB |
| | Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) |
| | Supports Dual-Channel mode |
| | Supports non-ECC, UDIMM memory |
| | Supports ECC UDIMM memory (non-ECC mode) |
| | Supports un-buffered memory |
| | |
| ONBOARD GRAPHICS | | 1x HDMI™ |
| | Support HDMITM 1.4, maximum resolution of 4K 24Hz* |
| | 1x DVI |
| | Support DVI-D, maximum resolution of 1920×1200 60Hz |
| | *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| | |
| SLOT | | 1x PCI-E x16 slot |
| | 1x PCI-E x1 slot |
| | PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU) |
| | PCI_E2 Gen PCIe 2.0 supports up to x1 (From Chipset) |
| | |
| STORAGE | | 1x M.2 |
| | M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| | 4x SATA 6G |
| | |
| RAID | | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices |
| | |
| USB | | 2x USB 2.0 (Rear) |
| | 4x USB 2.0 (Front) |
| | 4x USB 3.2 Gen1 Type A (Rear) |
| | 2x USB 3.2 Gen1 Type A (Front) |
| | |
| LAN | | Realtek® 8125 2.5Gbps LAN controller |
| | |
| AUDIO | | Realtek® ALC897 Codec |
| | 7.1-Channel High Definition Audio |
| | |
| INTERNAL IO | | 1x Power Connector(ATX_PWR) |
| | 1x Power Connector(CPU_PWR) |
| | 1x CPU Fan |
| | 1x System Fan |
| | 2x Front Panel (JFP) |
| | 1x Chassis Intrusion (JCI) |
| | 1x Front Audio (JAUD) |
| | 1x Com Port (JCOM) |
| | 1x TPM pin header(Support TPM 2.0) |
| | 4x USB 2.0 ports |
| | 2x USB 3.2 Gen1 Type A ports |
| | |
| OPERATING SYSTEM | | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| | |
| PCB INFO | | Matx |
| | 200mmx236mm |
