| CHIPSET | | INTEL Z790 | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| CPU | | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors | | | | | | | |
| | LGA 1700 | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| MEMORY | | 4x DDR5, Maximum Memory Capacity 192GB | | | | | | | | | | | | |
| | Memory Support 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz |
| | Max. overclocking frequency: | | | | | | | | | | | | | | |
| | • 1DPC 1R Max speed up to 7200+ MHz | | | | | | | | | | | | | |
| | • 1DPC 2R Max speed up to 6600+ MHz | | | | | | | | | | | | | |
| | • 2DPC 1R Max speed up to 6400+ MHz | | | | | | | | | | | | | |
| | • 2DPC 2R Max speed up to 5600+ MHz | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | Supports Intel® XMP3.0 OC | | | | | | | | | | | | | | |
| | Supports Dual-Controller Dual-Channel mode | | | | | | | | | | | | |
| | Supports non-ECC, un-buffered memory | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| ONBOARD GRAPHICS | | 1x HDMI™ | | | | | | | | | | | | | | | |
| | Support HDMI™ 2.1 HDR, maximum resolution of 4K 60Hz* | | | | | | | | | | | |
| | 1x DisplayPort | | | | | | | | | | | | | | | |
| | Support DP 1.4, maximum resolution of 4K 60Hz* | | | | | | | | | | | | |
| | *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| SLOT | | 3x PCI-E x16 slot | | | | | | | | | | | | | | | |
| | 1x PCI-E x1 slot | | | | | | | | | | | | | | | |
| | PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) | | | | | | | | | | | | |
| | PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) | | | | | | | | | | | | |
| | PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) | | | | | | | | | | | | |
| | PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| STORAGE | | 4x M.2 | | | | | | | | | | | | | | | | |
| | M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices | | | | | | | | |
| | M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices | | | | | | | | |
| | M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices | | | | | | | |
| | M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices | | | | | | | |
| | 6x SATA 6G | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| RAID | | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices | | | | | | | | | | |
| | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| USB | | 4x USB 2.0 (Rear) | | | | | | | | | | | | | | | |
| | 4x USB 2.0 (Front) | | | | | | | | | | | | | | | |
| | 2x USB 3.2 Gen1 Type A (Rear) | | | | | | | | | | | | | | |
| | 4x USB 3.2 Gen1 Type A (Front) | | | | | | | | | | | | | | |
| | 1x USB 3.2 Gen2 Type A (Rear) | | | | | | | | | | | | | | |
| | 1x USB 3.2 Gen2 Type C (Front) | | | | | | | | | | | | | | |
| | 1x USB 3.2 Gen2x2 Type C (Rear) | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| LAN | | Intel® 2.5Gbps LAN | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| WIRELESS LAN & BLUETOOTH | | Intel® Wi-Fi 6E | | | | | | | | | | | | | | | |
| | The Wireless module is pre-installed in the M.2 (Key-E) slot | | | | | | | | | | | |
| | Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps | | | | | | | | | | |
| | Supports 802.11 a/ b/ g/ n/ ac/ ax | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | Supports Bluetooth® 5.3, FIPS, FISMA | | | | | | | | | | | | | |
| | * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11. | | | | | | | | |
| | ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| AUDIO | | Realtek® ALC897 Codec | | | | | | | | | | | | | | |
| | 7.1-Channel High Definition Audio | | | | | | | | | | | | | |
| | Supports S/PDIF output | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| INTERNAL IO | | 1x Power Connector(ATX_PWR) | | | | | | | | | | | | | | |
| | 2x Power Connector(CPU_PWR) | | | | | | | | | | | | | |
| | 1x CPU Fan | | | | | | | | | | | | | | | |
| | 1x Pump Fan | | | | | | | | | | | | | | | |
| | 6x System Fan | | | | | | | | | | | | | | | |
| | 2x Front Panel (JFP) | | | | | | | | | | | | | | | |
| | 1x Chassis Intrusion (JCI) | | | | | | | | | | | | | | |
| | 1x Front Audio (JAUD) | | | | | | | | | | | | | | |
| | 1x TBT connector (JTBT, supports RTD3) | | | | | | | | | | | | | |
| | 1x Tuning Controller connector(JDASH) | | | | | | | | | | | | | |
| | 2x Addressable V2 RGB LED connector (JARGB_V2) | | | | | | | | | | | | |
| | 2x RGB LED connector(JRGB) | | | | | | | | | | | | | | |
| | 1x TPM pin header(Support TPM 2.0) | | | | | | | | | | | | | |
| | 4x USB 2.0 ports | | | | | | | | | | | | | | | |
| | 4x USB 3.2 Gen1 Type A ports | | | | | | | | | | | | | | |
| | 1x USB 3.2 Gen2 Type C ports | | | | | | | | | | | | | | |
| | 1x USB4 card connector (JTBT_U4_1, supports RTD3) | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| LED FEATURE | | 4x EZ Debug LED | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| BACK PANEL PORTS | | Keyboard / Mouse | | | | | | | | | | | | | | | |
| | DisplayPort | | | | | | | | | | | | | | | |
| | USB 2.0 | | | | | | | | | | | | | | | | |
| | 2.5G LAN Port | | | | | | | | | | | | | | | |
| | Wi-Fi / Bluetooth Antenna | | | | | | | | | | | | | | |
| | Audio Connectors | | | | | | | | | | | | | | | |
| | Flash BIOS Button | | | | | | | | | | | | | | | |
| | USB 2.0 | | | | | | | | | | | | | | | | |
| | HDMI™ 2.1 Port | | | | | | | | | | | | | | | |
| | USB 3.2 Gen 1 5Gbps Type-A | | | | | | | | | | | | | | |
| | USB 3.2 Gen 2×2 20Gbps Type-C | | | | | | | | | | | | | | |
| | USB 3.2 Gen 2 10Gbps Type-A | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| OPERATING SYSTEM | | Support for Windows® 11 64-bit, Windows® 10 64-bit | | | | | | | | | | | | |
| | | | | | | | | | | | | | | | | | |
| PCB INFO | | ATX | | | | | | | | | | | | | | | | |
| | 243.84mmx304.8mm | |
