Description
| General Information | ||||||
|---|---|---|---|---|---|---|
| 80 PLUS® | Gold | |||||
| Cybenetics Efficiency Level | TBA | |||||
| Cybenetics Noise Level | TBA | |||||
| Form Factor | ATX/EPS | |||||
| Dimensions | 140 × 150 × 86 mm | |||||
| Fan Information | ||||||
| Fan Size | 120 mm | |||||
| Fan Control | S²FC | |||||
| Fan Bearing | Fluid Dynamic Bearing | |||||
| Life Expectancy | 50,000 hours at 40 °C, 15% – 65% RH | |||||
| Cable Information | ||||||
| Modularity | Semi-Modular | |||||
| Cable Type | Webbed Cables (Attached) – Flat Black Cables (Modular) | |||||
| Electrical Features | ||||||
| Operating Temperature | 0 – 50 °C (Derating from 100% to 80% from 40 °C to 50 °C linearly) | |||||
| MTBF @ 25 °C, Excl. Fan | 100,000 hours | |||||
| AC Input | Full Range | |||||
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |||||
| Safety and Environmental | ||||||
| Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE | |||||
| Warranty | 7 Years | |||||
| Power Output | ||||||
| AC Input | 100 V – 240 V | |||||
| AC Input Current | 12 – 6 A | |||||
| AC Input Frequency | 50 Hz – 60 Hz | |||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Current | 20 A | 20 A | 70 A | 0.3 A | 3 A | |
| Maximum Power | 100 W | 840 W | 3.6 W | 15 W | ||
| Total Continuous Power | 850 W | |||||
