Description
Incorporating various high-quality components, the new TR2 S Series – models are rated from 350W to 700W – saves energy through its high efficiency of up to 86% and accommodates any mainstream build with the most demanding requirements. An embedded intelligent cooling fan delivers excellent airflow at an exceptionally low noise level. Additionally, the Single +12V rail design enables non-stop usage with stable and reliable performance.
| P/N | PS-TRS-0600NPCWEU-2 |
|---|---|
| WATTS | 600W |
| VENTILATEUR RGB | Non |
| FORMAT | ATX |
| MODEL | TRS-600AH2NK |
| TYPE | Intel ATX 12V 2.3 |
| MAX. OUTPUT CAPACITY | 600W |
| COULEUR | Black |
| DIMENSION ( W / H / D ) | 86mm x 150mm x 140mm |
| PFC (POWER FACTOR CORRECTION) | Active PFC |
| POWER GOOD SIGNAL | 100-500 msec |
| HOLD UP TIME | 16msec (minimum) within 60% load |
| INPUT CURRENT | 8A max |
| INPUT FREQUENCY RANGE | 50 Hz – 60 Hz |
| INPUT VOLTAGE | 230 Vac |
| OPERATING TEMPERATURE | 5℃ to +40℃ |
| OPERATING HUMIDITY | 20% to 85%,non-condensing |
| STORAGE TEMPERATURE | -40 ℃ to +55 ℃ |
| STORAGE HUMIDITY | 10% to 95%, non-condensing |
| SYSTÈME DE REFROIDISSEMENT | 120mm Fan: 1800 R.P.M. ± 10% |
| EFFICIENCY | 82-86% efficiency @ 20-100% load |
| MTBF | 100,000 hrs minimum |
| SAFETY APPROVAL | CE/CB/TUV |
| PCI-E 6+2PIN | PCI-E 6+2pin x 2 |
