Description
| GPU Specifications | |
|---|---|
| GPU | Radeon™ RX 5700 Graphics |
| GPU Architecture | RDNA Architecture |
| Manufacturing Process | 2nd Gen 7nm GPU |
| Base Clock | 1670 MHz |
| Game Clock | Up to 1815 MHz |
| Boost Clock | Up to 1925 MHz |
| Stream Processors | 2560 |
| Memory Specifications | |
| Memory Size | 8GB |
| Memory Type | GDDR6 |
| Memory Interface | 256-bit |
| Memory Clock Rate | 14 Gbps Effective |
| Display Specifications | |
| Maximum Displays | 4 |
| Maximum HDMI Resolution | 4096 × 2160 @ 60Hz |
| Maximum DisplayPort Resolution | 5120 × 2880 @ 60Hz |
| HDMI Output | 1 × HDMI |
| DisplayPort Output | 3 × DisplayPort 1.4 |
| Display Technology | DisplayPort 1.4 (HBR3) / DSC |
| Interface and API | |
| Bus Interface | PCI Express 4.0 |
| BIOS Support | Dual UEFI / Dual BIOS |
| DirectX | DirectX 12 |
| OpenGL | OpenGL 4.6 |
| OpenCL | OpenCL 2.0 |
| Shader Model | Shader Model 6.4 |
| Vulkan | Supported |
| SAPPHIRE Performance Features | |
| Cooling Technology | Dual-X Cooling Technology |
| Fan Configuration | Dual Fan |
| Fan Bearing | Two-Ball Bearing |
| Fan Control | Intelligent Fan Control IV, Precision Fan Control |
| Cooling Features | Robust VRM Cooling, Robust Memory Cooling |
| Backplate | Tough Metal Backplate |
| PCB Layers | Multi-layer PCB Design |
| Fan Quick Connect | Supported |
| Fuse Protection | Supported |
| Power Design | Free Flow |
| Software Support | TriXX, TriXX Boost |
| Lighting | Red LED Logo |
| AMD Graphics Features | |
| Radeon Software Features | Radeon™ Boost, Radeon™ Image Sharpening, Radeon™ Anti-Lag |
| AMD FidelityFX | Supported |
| Async Compute | Supported |
| Ray Tracing Audio Features | Radeon™ Rays Audio + True Audio Next |
| FreeSync Technology | Radeon™ FreeSync™ 2 HDR |
| Virtual Reality | Radeon™ VR Ready Premium |
| Video Streaming | Up to 8K |
| Power Efficiency | Supported |
| Physical Specifications | |
| Form Factor | 2.3-Slot, ATX |
| Dimensions | 254 × 135 × 46.5 mm |
| Cooling Design | Dual-X Cooling, Dual Fan |
| Power Requirements | |
| Power Consumption | 241W |
| Recommended PSU | 650W |
| Minimum PSU | 600W |
| Power Connectors | 1 × 8-pin + 1 × 6-pin |
| System Requirements | |
| Operating Systems | Windows 11, Windows 10, Windows 7 (64-bit) |
| Minimum System Memory | 8GB RAM |
| Recommended System Memory | 16GB RAM |
| Motherboard Requirement | PCI Express-based motherboard with one available x16 graphics slot |
| Gaming Performance | |
| Game Index | Extreme 1440P |
