| CPU | | AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors |
| | *Refer to www.asus.com for CPU support list. |
| | |
| Memory | | 4 x DIMM, Max. 128GB, DDR4 4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz, Un-buffered Memory* |
| | Dual Channel Memory Architecture |
| | * ECC Memory (ECC mode) support varies by CPU. |
| | * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types. |
| | |
| Graphics | | 1 x DisplayPort 1.2 |
| | 1 x HDMITM 2.1(4K@60HZ) |
| | *Graphics specifications may vary between CPU types. |
| | |
| Expansion Slots | | AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors |
| | 1 x PCIe 4.0 x16 slot (supports x16 mode) |
| | AMD Ryzen™ 5000 G-Series/ 4000 G-Series Desktop Processors |
| | 1 x PCIe 3.0 x16 slot (supports x16 mode) |
| | AMD B550 Chipset |
| | 1 x PCIe 3.0 x16 slot (supports x4 mode)* |
| | 3 x PCIe 3.0 x1 slot* |
| | *PCIE 3.0 X16_2 runs x1 mode when any of the PCIe 3.0 x1 slots is occupied. |
| | **Support PCIe bifurcation for RAID on CPU function. |
| | |
| Storage | | Supports 2 x M.2 slots and 6 x SATA 6Gb/s ports |
| | AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors : |
| | M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes) |
| | AMD Ryzen™ 5000 G-Series/ 4000 G-Series Desktop Processors |
| | M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes) |
| | AMD B550 Chipset |
| | M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)* |
| | 6 x SATA 6Gb/s ports |
| | Support Raid 0, 1, 10 |
| | *M2_2 shares bandwidth with SATA6G_56. When M.2_2 is populated, SATA6G_56 will be disabled. |
| | |
| Ethernet | | 1 x Realtek 2.5Gb Ethernet |
| | |
| Wireless & Bluetooth | | 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) |
| | Supports 2.4/5GHz frequency band |
| | Bluetooth v5.2* |
| | *Bluetooth v5.2 function will be ready in Windows 11 or later. |
| | |
| USB | | Rear USB:Total 8 ports |
| | 2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C®) |
| | 4 x USB 3.2 Gen 1 ports (4 x Type-A) |
| | 2 x USB 2.0 ports (2 x Type-A) |
| | Front USB:Total 6 ports |
| | 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports |
| | 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| | |
| Audio | | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| | – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking |
| | – Supports up to 24-Bit/192 kHz playback |
| | Audio Features |
| | – Audio Shielding |
| | – Rear optical S/PDIF out port |
| | – Premium audio capacitors |
| | – Dedicated audio PCB layers |
| | – Audio Cover |
| | |
| Back Panel I/O Ports | | 2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C®) |
| | 4 x USB 3.2 Gen 1 ports (4 x Type-A) |
| | 2 x USB 2.0 ports (2 x Type-A) |
| | 1 x DisplayPort |
| | 1 x HDMI™ port |
| | 1 x ASUS Wi-Fi Module |
| | 1 x Realtek 2.5Gb Ethernet port |
| | 5 x Audio jacks |
| | 1 x Optical S/PDIF out port |
| | 1 x BIOS FlashBack™ button |
| | |
| Internal I/O Connectors | | Fan and Cooling related |
| | 1 x 4-pin CPU Fan header(s) |
| | 1 x 4-pin CPU OPT Fan header(s) |
| | 1 x 4-pin AIO Pump header(s) |
| | 3 x 4-pin Chassis Fan header(s) |
| | Power related |
| | 1 x 24-pin Main Power connector |
| | 1 x 8-pin +12V Power connector |
| | Storage related |
| | 2 x M.2 slots (Key M) |
| | 6 x SATA 6Gb/s ports |
| | USB |
| | 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports |
| | 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports |
| | Miscellaneous |
| | 2 x AURA Addressable Gen 2 header(s) |
| | 2 x AURA RGB header(s) |
| | 1 x Clear CMOS header |
| | 1 x COM Port header |
| | 1 x Front Panel Audio header (AAFP) |
| | 1 x SPI TPM header (14-1pin) |
| | 1 x 20-3 pin System Panel header |
| | 1 x Thermal Sensor header |
| | 1 x Thunderbolt header |
| | |
| Special Features | | ASUS TUF PROTECTION |
| | – ASUS DIGI+ VRM (Digital power design with Dr. MOS) |
| | – ASUS Enhanced DRAM Overcurrent Protection |
| | – ASUS ESD Guards |
| | – TUF LANGuard |
| | – ASUS Overvoltage Protection |
| | – ASUS SafeSlot |
| | – ASUS Stainless-Steel Back I/O |
| | ASUS Q-Design |
| | – ASUS Q-DIMM |
| | – ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
| | – ASUS Q-Slot |
| | ASUS Thermal Solution |
| | – Aluminum M.2 heatsink |
| | ASUS EZ DIY |
| | – BIOS FlashBack™ button |
| | – BIOS FlashBack™ LED |
| | – Procool |
| | AURA Sync |
| | – AURA RGB header(s) |
| | – Addressable Gen 2 RGB header(s) |
| | |
| Software Features | | ASUS Exclusive Software |
| | Armoury Crate |
| | – Aura Sync |
| | – Two-Way AI Noise Cancelation |
| | AI Suite 3 |
| | – Performance And Power Saving Utility |
| | TurboV EVO |
| | EPU |
| | Digi+ VRM |
| | Fan Xpert 4 |
| | PC Cleaner |
| | – EZ update |
| | – System Information |
| | Aura Creator |
| | TUF GAMING CPU-Z |
| | DTS Custom for GAMING Headsets |
| | Norton Anti-virus software (Free Trial for 60 days) |
| | WinRAR |
| | UEFI BIOS |
| | ASUS EZ DIY |
| | – ASUS CrashFree BIOS 3 |
| | – ASUS EZ Flash 3 |
| | – ASUS UEFI BIOS EZ Mode |
| | |
| BIOS | | 256 Mb Flash ROM, UEFI AMI BIOS |
| | |
| Form Factor | | ATX |
| | 30.5cm x 24.4cm |
