| CPU |
Supported CPUs |
6th & 7th Gen Intel Core i7/i5/i3, Pentium, Celeron (LGA1151) |
| CPU |
L3 Cache |
Varies with CPU |
| Chipset |
Chipset |
Intel B250 Express Chipset |
| Memory |
DIMM Slots |
4 x DDR4 |
| Max Capacity |
Up to 64 GB |
| Channels |
Dual channel |
| Speeds Supported |
DDR4 2400 / 2133 MHz* |
| ECC Support |
ECC Un-buffered DIMMs (non-ECC mode), Non-ECC Un-buffered DIMMs |
| XMP Support |
Yes (7th gen CPU required) |
| OS Limitation |
Windows 32-bit shows less than 4GB |
| Onboard Graphics |
Integrated Graphics |
Intel HD Graphics |
| D-Sub |
1920×1200@60Hz |
| DVI-D |
1920×1200@60Hz (No adapter support) |
| HDMI |
4096×2160@24Hz (HDMI 1.4) |
| Display Support |
Up to 3 displays |
| Shared Memory |
Max 1 GB |
| Audio |
Codec |
Realtek ALC892 |
| Channels |
2/4/5.1/7.1, S/PDIF Out |
| LAN |
Controller |
Intel GbE LAN (10/100/1000) |
| Expansion Slots |
PCI Express x16 |
1 x16, 1 x4 |
| PCI Express x1 |
2 |
| PCI |
2 |
| Standard |
PCIe 3.0 |
| Notes |
PCIEX4 shares bandwidth with SATA Express |
| Multi-GPU |
AMD Quad-GPU CrossFireX, 2-Way CrossFire |
| Storage |
M.2 |
1 x M.2 Socket 3 (2242/2260/2280/22110 SATA & PCIe x4/x2) |
| SATA Express |
1 (not compatible with regular SATA) |
| SATA 6Gb/s |
6 x connectors |
| Note |
SATA Express affects PCIEX4 slot bandwidth |
| USB |
USB 3.1 Gen 1 |
6 ports (4 back panel, 2 internal) |
| USB 2.0/1.1 |
6 ports (2 back panel, 4 internal) |
| Internal USB |
1 x USB 3.1 Gen 1 header, 2 x USB 2.0 headers |
| Internal I/O |
Power Connectors |
24-pin ATX, 8-pin ATX 12V |
| Fan Headers |
1 CPU, 3 system |
| Audio/SATA |
Front audio header, S/PDIF, 6x SATA 6Gb/s |
| Legacy |
Serial, Parallel, TPM headers |
| Other |
Front panel header, Clear CMOS jumper |
| Back Panel |
Display Ports |
1 x D-Sub, 1 x DVI-D, 1 x HDMI |
| USB Ports |
4 x USB 3.1, 2 x USB 2.0 |
| Audio Jacks |
6 (7.1-channel) |
| Others |
1 x PS/2, 1 x RJ-45 |
| I/O Controller |
Chip |
iTE I/O Controller |
| H/W Monitoring |
Sensors |
Voltage, Temperature, Fan speed |
| Alerts |
Overheat & Fan fail warning, Fan speed control |
| BIOS |
Type |
2 x 64 Mbit AMI UEFI BIOS, DualBIOS |
| Support |
PnP 1.0a, DMI 2.7, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
Utilities |
APP Center (varies by model) |
| Software |
Norton Internet Security OEM, cFosSpeed |
| Optane Support |
Yes |
| 3TB+ Unlock, Q-Flash, Xpress Install |
Supported |
| Operating System |
Supported OS |
Win 10 (7th Gen CPU), Win 10/8.1/7 (6th Gen CPU) |
| Note |
Windows 7 requires USB Installation Tool |
| Form Factor |
Type |
ATX |
| Dimensions |
30.5 cm x 22.5 cm |
| Remark |
Linux drivers from vendors or 3rd parties. Limited Win9X/ME/2000/XP support. |
|
