Description
| Specification | Details |
|---|---|
| CPU | Support for 9th and 8th Generation Intel® Core™ i9/i7/i5/i3, Intel® Pentium® and Intel® Celeron® processors in the LGA1151 package L3 cache varies with CPU Please refer to the CPU Support List for more information. |
| Chipset | Intel® Z390 Express Chipset |
| Memory | 4 x DDR4 DIMM sockets, up to 128GB (32GB single DIMM capacity) Dual channel memory architecture DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz ECC Un-buffered DIMM 1Rx8/2Rx8 (non-ECC mode) Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 Support for XMP memory modules |
| Onboard Graphics | Intel® HD Graphics support 1 x HDMI port, up to 4096×2160@30 Hz HDMI 1.4, HDCP 2.2 Maximum shared memory: 1GB Actual support may vary by CPU |
| Audio | Realtek® ALC1220-VB codec High Definition Audio 2/4/5.1/7.1-channel S/PDIF Out support |
| LAN | Intel® GbE LAN chip (10/100/1000 Mbit) |
| Expansion Slots | 1 x PCI Express x16 slot, running at x16 (PCIEX16) 1 x PCI Express x16 slot, running at x4 (PCIEX4) 4 x PCI Express x1 slots PCI Express 3.0 standard PCIEX4 shares bandwidth with PCIEX1_3 |
| Multi-Graphics Technology | AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies |
| Storage Interface | 1 x M.2 connector (M2A), Socket 3, M key, 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support 1 x M.2 connector (M2M), Socket 3, M key, 2242/2260/2280 SATA and PCIe x4/x2 SSD support 6 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5 and RAID 10 support Intel® Optane™ Memory Ready |
| USB | 2 x USB 3.1 Gen 2 Type-A ports on back panel 1 x USB Type-C™ port with USB 3.1 Gen 1 support via internal header 6 x USB 3.1 Gen 1 ports 8 x USB 2.0/1.1 ports |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 2 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan/water cooling pump headers 2 x digital LED strip headers 2 x digital LED strip power select jumpers 2 x RGB LED strip headers 1 x front panel header 1 x front panel audio header 1 x USB Type-C™ port 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x S/PDIF Out header 1 x TPM header 1 x Thunderbolt™ add-in card connector 1 x Clear CMOS jumper |
| Back Panel Connectors | 4 x USB 2.0/1.1 ports 1 x HDMI port 4 x USB 3.1 Gen 1 ports 2 x USB 3.1 Gen 2 Type-A ports 1 x RJ-45 port 1 x Optical S/PDIF Out connector 5 x Audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Overheating warning Fan fail warning Fan speed control |
| BIOS | 2 x 128 Mbit flash AMI UEFI BIOS DualBIOS™ support PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | APP Center 3D OSD @BIOS AutoGreen Cloud Station EasyTune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart TimeLock Smart HUD Smart Survey System Information Viewer USB Blocker V-Tuner Q-Flash Xpress Install |
