Description
| Category | Specification |
|---|---|
| CPU Socket | Socket AM5 |
| CPU Support | AMD Ryzen™ 9000, 8000 & 7000 Series Desktop Processors |
| Chipset | AMD B650 |
| Memory | 4 × DDR5 DIMM Slots (Max 192GB) Supports DDR5 8000+(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200 / 5000 / 4800 MHz Dual Channel Architecture ECC & Non-ECC Unbuffered Memory AMD EXPO™ Support OptiMem II |
| Integrated Graphics Outputs | 1 × DisplayPort 1.4 (Up to 8K@60Hz) 1 × HDMI 2.1 (Up to 4K@60Hz) |
| Expansion Slots | Ryzen 9000 / 7000: • 1 × PCIe 5.0 x16Ryzen 8000: • 1 × PCIe 4.0 x16 (x8/x4 mode) B650 Chipset: |
| Storage | Total: 3 × M.2 + 4 × SATA 6Gb/s
Ryzen 9000 / 7000: Ryzen 8000: B650: AMD RAID 0/1/10 (NVMe & SATA) |
| LAN | Intel® 2.5Gb Ethernet (Intel I225-V) with ASUS LANGuard |
| Wireless | Wi-Fi 6E (2×2) Bluetooth 5.2 |
| Rear USB Ports | 1 × USB 3.2 Gen 2×2 Type-C 3 × USB 3.2 Gen 2 (2 × Type-A, 1 × Type-C) 4 × USB 3.2 Gen 1 Type-A 4 × USB 2.0 Type-A |
| Front USB | 1 × USB 3.2 Gen 2 Type-C Header 1 × USB 3.2 Gen 1 Header (2 Ports) 2 × USB 2.0 Headers (4 Ports) |
| Audio | ROG SupremeFX ALC4080 7.1 HD Audio Savitech SV3H712 AMP 120dB Playback / 113dB Recording 32-bit / 384kHz Playback Premium Audio Capacitors SupremeFX Shielding |
| Rear I/O | 1 × USB 3.2 Gen 2×2 Type-C 3 × USB 3.2 Gen 2 4 × USB 3.2 Gen 1 4 × USB 2.0 1 × DisplayPort 1 × HDMI 1 × Wi-Fi Module 1 × Intel 2.5Gb LAN 5 × Audio Jacks 1 × BIOS FlashBack Button |
| Internal Headers | Cooling: 1 × CPU Fan 1 × CPU OPT Fan 1 × AIO Pump 4 × Chassis FanPower: 24-pin ATX 8-pin CPU 4-pin CPU Storage: USB: Other: |
| Special Features | Extreme Engine Digi+ 5K Black Metallic Capacitors BIOS FlashBack PCIe Slot Q-Release M.2 Q-Latch Q-LED Q-DIMM SafeSlot SafeDIMM Pre-mounted I/O Shield ProCool FlexKey Aura Sync RGB |
| Software | Armoury Crate AI Suite 3 Fan Xpert 4 Aura Creator Aura Sync AIDA64 Extreme (60-day Trial) GameFirst VI Sonic Studio III Sonic Radar III DTS Sound Unbound MyASUS WinRAR |
| BIOS | 256Mb UEFI AMI BIOS |
| Manageability | Wake-on-LAN (WOL), PXE |
| Accessories | 2 × SATA Cables M.2 Thermal Pad Wi-Fi Antenna Cable Ties M.2 Q-Latch Kit ROG Key Chain ROG Stickers Thank You Card M.2 Rubber Packages User Guide |
| Operating System | Windows® 10 64-bit / Windows® 11 64-bit |
| Form Factor | ATX (30.5 × 24.4 cm) |
