Dimension: 628.3 x 337 x 763 mm
Description
| P/N | CA-1Q4-00M6WN-00 |
|---|---|
| SERIES | AH Series |
| MODEL | AH T600 Snow |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 628.3 x 337 x 763 mm (27.74 x 13.3 x 30 inch) |
| NET WEIGHT | 20.64 kg / 45.5 lb |
| PANEL | 5mm Tempered Glass x 2 |
| COLOR | Exterior & Interior : White |
| MATERIAL | SPCC |
| DRIVE BAYS -ACCESSIBLE -HIDDEN |
|
| EXPANSION SLOTS | 8 |
| MOTHERBOARDS | 6.7โ x 6.7โ (Mini ITX), 9.6โ x 9.6โ (Micro ATX), 12โ x 9.6โ (ATX), 12โ x 10.5โ (E-ATX) |
| I/O PORT | 1 x USB 3.1 (Gen 2) Type C, USB 3.0 x 2, USB 2.0 x 1, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | Front: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm 3 x 140mm or 2 x 140mm or 1 x 140mm Top: 3 x 120mm or 2 x 120mm or 1 x 120mm 2 x 140mm or 1 x 140mm Right: 3 x 120mm or 2 x 120mm or 1 x 120mm 2 x 140mm or 1 x 140mm |
| RADIATOR SUPPORT | Front: 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm 1 x 420mm or 1 x 280mm or 1 x 140mm Top: 1 x 360mm or 1 x 240mm or 1 x 120mm 1 x 280mm or 1 x 140mm Right: 1 x 360mm or 1 x 240mm or 1 x 120mm 1 x 280mm or 1 x 140mm |
| CLEARANCE | CPU cooler height limitation: 195mm VGA length limitation: 300mm(With Water Pump) 440mm(Without Water Pump) PSU length limitation: 200mm |
